White light
- General traditional lighting, outdoor landscape lighting application replacement;
- Anti-vulcanization process, high air tightness;
- High current drive resistance.
| Part No. | L/F Type | Color | CRI(min) | ф (lm) | Efficacy(lm/w) | VF(V) | IF(mA) | Po(W) | 50%PowerAngle |
| RF-Q30PA27A-24-J2 | Round | 2700K | 70 | 148 | 162 | 5.8-6.2 V | 150 | 0.9 | 120 |
| RF-Q30PA30A-24-J2 | 3000K | 70 | 152 | 166 | |||||
| RF-Q30PA40A-24-J2 | 4000K | 70 | 158 | 173 | |||||
| RF-Q30PA50A-24-J2 | 5000K | 70 | 158 | 173 | |||||
| RF-Q30PA57A-24-J2 | 5700K | 70 | 158 | 173 | |||||
| RF-Q30PA65A-24-J2 | 6500K | 70 | 157 | 172 | |||||
| RF-Q30PA27B-24-J2 | Round | 2700K | 80 | 135 | 148 | 5.8-6.2 V | 150 | 0.9 | 120 |
| RF-Q30PA30B-24-J2 | 3000K | 80 | 142 | 155 | |||||
| RF-Q30PA40B-24-J2 | 4000K | 80 | 148 | 162 | |||||
| RF-Q30PA50B-24-J2 | 5000K | 80 | 148 | 162 | |||||
| RF-Q30PA57B-24-J2 | 5700K | 80 | 148 | 162 | |||||
| RF-Q30PA65B-24-J2 | 6500K | 80 | 147 | 161 |
If you're interested in our products or service, you can choose to leave your information here, and we will be in touch with you shortly.
- Small size meets the high density requirement;
- High mechanical strength, resistant to bending without breaking;
- Single Bin supply, good color consistency;
- Intellectual property protection at home and abroad.
- 1W/㎡ high heat dissipation ceramic3535
- High light efficiency
- High heat dissipation
- High integration, high light efficiency, high CRI
- Q3030 Size：3.0*3.0*0.65mm
- P3030 Size：3.0*3.0*0.55mm
- EMC lead frame with high heat resistance, good air tightness, and UV resistance
- Good color consistency，≤3SDCM is optional
- LM80 L70>54Khrs，L90>36Khrs
- High power,High brightness
- Good reliability
- Rich Color
- Uniform color
- Customizable Specification
- viewing angle:120°
- Moisture sensitivity level: Level 1.
- Suitable for all SMT assembly and solder process.
- Available on tape and reel.
- RoHS compliant.
- Ceramics Package.
- viewing angle:120°
- High reliability, High CRl, High TLCI.
- Suitable for all SMT assembly and solder process.
- Available on tape and reel.
- RoHS compliant.
Features:
- Ceramics Package.
- viewing angle:120°. 120°
- High reliability.
- Suitable for all SMT assembly and solder process.
- Available on tape and reel.
- RoHS compliant.
Application:
- Warning lights, Downlights, Wash wall lights, Spot lights, Street lights.
- Plant lighting, Landscape lighting, Stage photography light.
- Hotels, markets, offices, household and other indoor uses.
- General use.
- Anti-vulcanization, high light efficiency;
- MSL3; Large luminous surface;
- Meet customers' needs for product continuation.
-SCDM ≤3, can provide SCDM=1 products;
- Various models and specifications;
- LM-80
- According to different application needs to provide a variety of optional packaging styles, can provide front and side stickers, different strength to meet the various needs of hard and soft lamp;
- ANSI/ERP, full color temperature coverage;
- Special color area/color point customization.
-Product maintenance to meet the needs of customers for product continuation;
-Rich and diverse products, can provide customers with customized solutions;
- It is applied to the bulletin board project of the community, the advertisement board of the bus and subway, the construction display project, the exhibition center, etc.
- Large luminescent surface, to meet the needs of customer product continuation;
- According to different application needs to provide a variety of optional packaging styles, can provide front and side stickers, different strength to meet the various needs of hard and soft lamp;
- It is applied to the bulletin board project of the community, the advertisement board of the bus and subway, the construction display project, the exhibition center, etc.
- Industry first;
- Mass production with excellent consistency of light and color;
- Panchromatic region, full display finger, full spectrum;
- Compact and flexible, suitable for different width, different density, different combination of light strip light belt needs;
- LM-80
- Miniaturization facilitates application space design;
- Can replace CHIP LED, with better reliability, application experience of large companies at home and abroad;
- Customized color book with rich models and specifications;
- High mechanical strength, can withstand bending.
- Energy saving and environmental protection, long life;
- The product is very ornamental, the color is novel and beautiful, can create a variety of atmosphere according to the product design;
- With particularity, the diversification of products can meet the particularity of people's requirements for lighting, reflecting different personalized rich models and specifications;
- Small size, easy to design;
- Application experience of large domestic and foreign companies.
- Applied to line lights, etc.;
- Vertical table sticker package;
- Color tolerance ≤5SDCM;
- PCT material;
- Package size 2.8*3.5*0.7mm; ;
- LM80, L70>54Khrs,L90>36Khrs;
- Meet Rohs requirements.
- Vertical table sticker package
- the PCT material
- Anti-vulcanization process, good air tightness
- Package size 2.8*3.5*0.7mm
- Color tolerance ≤5SDCM
- LM80 ,L70>54Khrs,L90>36Khrs
- General traditional lighting, outdoor landscape lighting application replacement;
- anti-vulcanization process, high air tightness;
- Resistant to large current drive;
- EMC package, large luminous Angle.
- General traditional lighting, outdoor landscape lighting application replacement;
- anti-vulcanization process, high air tightness;
- Resistant to high current drive.
-Applied to intelligent bulb, outdoor lighting and other fields;
- EMC material, high air tightness, small integrated volume;
- Good color purity, high temperature resistance, low thermal resistance & LT; 15 ℃ / W.
- Used in security alarm lights, outdoor lighting and other fields;
- EMC material, high air tightness, small integrated volume;
- Good color purity, high temperature resistance, low thermal resistance & LT; 15 ℃ / W.
- Used in the field of security lighting;
- EMC material, high air tightness, small integrated volume;
- Good color purity, high temperature resistance, low thermal resistance & LT; 15 ℃ / W.
-Used in spotlights, projection lamps, industrial and mining lamps, street lamps and other fields;
- EMC material, high air tightness, small integrated volume;
- Good color purity, high temperature resistance, low thermal resistance & LT; 15 ℃ / W;
- Good light and color consistency, full color temperature ≤5SDCM coverage.
- Provide RG0 blue light free application scheme;
- Used in blackboard lights, classroom lights, etc.;
- Vertical table sticker package;
- Color tolerance ≤5SDCM;
- PPA, PCT material;
- Package size 2.8*3.5*0.7mm; ;
- LM80, L70>54Khrs,L90>36Khrs;
- Meet Rohs requirements.
- Continuous spectral saturation, simulates sunlight;
- Used in human lighting, table lamp, eye protection lighting, etc.;
- High light efficiency, high heat resistance Tj max=135℃;
- High sulfur resistance, IPSL coating process;
- Health, sunfeel;
- High reliability, ≥500 rounds of cold flushing;
- Closest to sunlight, effectively reduce the harm of blue light from LED lighting source.
- Continuous spectral saturation, 98 display;
- Effectively reduce the harm of blue light;
- Provide RG0 blue light free application scheme;
- The products are used in educational lighting, health lighting, home furnishing, eye protection table lamp, etc.
- Anti-vulcanization process, good air tightness;
- Applied to linear spherical bubbles, etc.;
- Vertical table sticker package;
- Color tolerance ≤5SDCM;
- PPA, PCT material;
- Package size 2.8*3.5*0.7mm; ;
- LM80, L70>54Khrs,L90>36Khrs;
- Meet Rohs requirements.
- Used for lamp tube, lamp strip, lamp belt, etc.;
- Vertical table sticker package;
- Color tolerance ≤5SDCM;
- PPA, PCT material;
- Package size 2.8*3.5*0.7mm; ;
- LM80, L70>54Khrs,L90>36Khrs;
- Meet Rohs requirements.
- Anti-vulcanization process, good air tightness;
- Used in ceiling lights, downlights, etc.;
- Vertical table sticker package;
- Color tolerance ≤5SDCM;
- PPA, PCT material;
- Package size 2.8*3.5*0.7mm; ;
- LM80, L70>54Khrs,L90>36Khrs;
- Meet Rohs requirements
- Anti-vulcanization process, good air tightness;
- Used in bulb lamp, etc.;
- Vertical table sticker package;
- Color tolerance ≤5SDCM;
- PPA, PCT material;
- Package size 2.8*3.5*0.7mm; ;
- LM80, L70>54Khrs,L90>36Khrs;
- Meet Rohs requirements.
