Automotive Exterior Lighting
- Vertical table paste package, excellent anti-vulcanization performance;
- Package size 3.0*3.0*0.55mm;
- AEC-Q102 authentication.
| Part No. | Luminous Flux(lm) | X/Y/λd(nm) | VF(V) | IF(mA) | 2θ1/2（°） | Rthj-sel. (K/W) | TJMax(°C) | Color |
| RF-A1E30-R22H-R8 | 55 | 622 | 2 | 350-400.. | 120 | 12 | 150 | Orange |
| RF-A2E30-W56E-A9B | 145 | (0.33, 0.34) | 6 | 150-200. | 120 | 12 | 150 | White |
| RF-A1E30-WYSH-B8 | 60 | (0.57, 0.42) / 590 | 3 | 350-400.. | 120 | 12 | 150 | PC Amber |
If you're interested in our products or service, you can choose to leave your information here, and we will be in touch with you shortly.
- Vertical table paste package, excellent anti-vulcanization performance;
- Package size 2.7*2.0*0.55mm;
AEC -- Q102 certification
- Vertical table paste package, excellent anti-vulcanization performance
- Single LED dual color design
- Package size 3.0*3.0*0.65mm
- AEC-Q102 authentication.
- Vertical table paste package, excellent anti-vulcanization performance;
- Package size 2.7*2.0*0.55mm;
- AEC-Q102 authentication.
- Vertical table paste package, excellent anti-vulcanization performance;
- Package size 3.5*2.8*1.85mm;
- AEC-Q102 authentication.
- Vertical table paste package, excellent anti-vulcanization performance;
- Package size 3.5*3.5*1.9mm;
- AEC-Q102 authentication.
- Vertical table paste package, excellent anti-vulcanization performance;
- AEC-Q102 authentication.
- Vertical table paste package, excellent anti-vulcanization performance;
- Package size 4.3*3.0*0.8mm;
- AEC-Q102 authentication.
- Vertical table paste package, excellent anti-vulcanization performance;
- Package size 3.0*3.0*0.8mm;
- AEC-Q102 authentication.
- Vertical table paste package, excellent anti-vulcanization performance;
- Package size 3.0*3.0*0.8mm;
- AEC-Q102 authentication.
- Vertical table paste package, excellent anti-vulcanization performance;
- Package size 2.0*1.6*0.8mm;
- AEC-Q102 authentication.
