Home page Product center 3528 PLCC4 0.2W series

3528 PLCC4 0.2W series

Automotive Exterior Lighting

Characteristics of the

- Vertical table paste package, excellent anti-vulcanization performance;

- Package size 3.5*2.8*1.85mm;

- AEC-Q102 authentication.

3528 PLCC4 0.2W series
3528 PLCC4 0.2W series
3528 PLCC4 0.2W series
3528 PLCC4 0.2W series
3528 PLCC4 0.2W series
3528 PLCC4 0.2W series
3528 PLCC4 0.2W series
3528 PLCC4 0.2W series

Product Parameters

Part No.Iv (RCM)X/Y/λd(nm)VF(V)IF(mA)2θ1/2(°)Rthj-sel. (K/W)TJMax(°C)Color
RF-A2A31-Y898-Y32800589250-70120130125Yellow
RF-A2A31-R228-R42800622250-70120130125Red
RF-A2A31-R328-R52300632250-70120130125Red
RF-A2A31-W5S8-A46500(0.33, 0.34)350-70120130125White
RF-A2A31-HY8-A65000(0.57, 0.42) / 590350-70120130125PC
50-70Amber






Product Documents
