Automotive Interior Lighting
- Applied to switches, keys, etc.;
- Vertical table paste package, a variety of colors can be selected;
- Package size 1.6*0.8*0.55mm, small size for flexible design;
- AEC-Q101 certification.
Product | Power | Color | Ta @25℃(TYP.) | Max current (mA) | viewing angle （°） | ESDwithstand voltage()HBM | automotie standard | |||
IF(mA) | vf(V) | Flux/Iv | XY/Wd | |||||||
RF-B1P08-W752-A32 | 0.01W | White | 5 | 2.6-3.0 | 585-650-720-800 | FFG/FFH/FFI （0.304,0.297） | 20 | 120 | 2000 | AEC-Q101 |
RF-A2P08-WBE2-A1 | 0.01W | White | 5 | 2.6-3.0 | 280-350-430-530 | BL1/BL2 （0.1826,0.263) | 20 | 120 | 2000 | AEC-Q101 |
RF-A2P08-R315-R0 | 0.04W | Red | 20 | 2.0-2.6 | 100-120-150-180 | 627.5-630-632.5-635 | 20 | 120 | 2000 | AEC-Q101 |
RF-A2P08-O055-O1 | 0.06W | Orange | 20 | 2.0-2.6 | 150-180-230-350 | 602.5-605-607.5-610 | 20 | 120 | 2000 | AEC-Q101 |
RF-A2P08-Y905-Y0 | 0.04W | Yellow | 20 | 2.0-2.6 | 230-280-350-430 | 585-587.5-590-592.5 | 20 | 120 | 2000 | AEC-Q101 |
RF-A2P08-G195-A2 | 0.06W | Green | 20 | 2.8-3.4 | 1200-1500-1800-2300 | 515-517.5-520-522.5-525 | 20 | 120 | 2000 | AEC-Q101 |
If you're interested in our products or service, you can choose to leave your information here, and we will be in touch with you shortly.
- Applied to switches, keys, etc.;
- Vertical table paste package, a variety of colors can be selected;
- Package size 2.2*1.4*1.3mm, small size for flexible design;
- AEC-Q101 certification.
- Applied to switches, instruments, buttons, etc.;
- Vertical table paste package, a variety of colors can be selected;
- Package size 3.5*2.8*1.85mm;
- AEC-Q101 certification.
- Vertical table paste package, excellent anti-vulcanization performance;
- Package size 3.5*2.8*3.25mm, a variety of colors optional;
- AEC-Q102 authentication.
- Vertical table paste package, excellent anti-vulcanization performance;
- Package size 3.5*2.8*3.5mm, a variety of colors optional;
- AEC-Q102 authentication.
- Vertical table mount package;
- EMC material, package size 3.0*1.4*0.52mm;
- AEC-Q102 authentication.
- Vertical table paste package, excellent anti-vulcanization performance;
- Package size 2.7*2.0*0.55mm;
- AEC -- Q102 certification
- PLCC2 Package
- Extremely wide viewing angle.
- Suitable for all SMT assembly and solder process.
- Available on tape and reel.
- Moisture sensitivity level: Level 2.
- Compliance with RoHS and REACH.
- Qualifications: The product qualification test plan is based on the guidelines of AEC-Q101 Stress Test Qualification for Automotive Grade Discrete Semiconductors
- PLCC4 Package.
- Extremely wide viewing angle.
- Suitable for all SMT assembly and solder process.
- Available on tape and reel.
- Moisture sensitivity level: Level 3.
- Compliance with RoHS and REACH.
- Qualifications: The product qualification test plan is based on the guidelines of AEC-Q102Stress Test Qualification for Automotive Grade Discrete Semiconductors
- PLCC4 Package.
- Extremely wide viewing angle.
- Suitable for all SMT assembly and solder process.
- Available on tape and reel.
- Moisture sensitivity level: Level 2.
- Compliance with RoHS and REACH.
- Qualifications: The product qualification test plan is based on the guidelines of AEC-Q101Stress Test Qualification for Automotive Grade Discrete Semiconductors
- Vertical table paste package, excellent anti-vulcanization performance;
- Package size 3.5*3.5*1.9mm;
- AEC-Q102 authentication.
- EMCPackage.
- Extremely wide viewing angle.
- Suitable for all SMT assembly and solder process.
- Available on tape and reel.
- Moisture sensitivity level: Level 2.
- Compliance with RoHS and REACH.
- Qualifications: The product qualification test plan is based on the guidelines of AEC-Q101 Stress Test Qualification for Automotive Grade Discrete Semiconductors
- EMCPackage.
- Extremely wide viewing angle.
- Suitable for all SMT assembly and solder process.
- Available on tape and reel.
- Moisture sensitivity level: Level 2.
- Compliance with RoHS and REACH.
- Qualifications: The product qualification test plan is based on the guidelines of AEC-Q101 Stress Test Qualification for Automotive Grade Discrete Semiconductors
- EMCPackage.
- Extremely wide viewing angle.
- Suitable for all SMT assembly and solder process.
- Available on tape and reel.
- Moisture sensitivity level: Level 2.
- Compliance with RoHS and REACH.
- Qualifications: The product qualification test plan is based on the guidelines of AEC-Q101 Stress Test Qualification for Automotive Grade Discrete Semiconductors
